250W Series
Information
ATM250T-□XXX
XXX = Output Voltage
□= P : C14
A : C18
Features:
* IEC/EN/ANSI/AAMI ES60601-1
* Electromagnetic compatibility: IEC60601-1-2
* Protection method: 2 X MOPP
* Regulated output with low ripple and noise
* Meets safety agency requirements and has passed EMI/EMS certification
* Modifications and customized designs available
* 2-year warranty
Output Specifications
| Model | Output Voltage | Output Current | Watts |
| ATM250T-□120 | 12.0V | 20.00A | 240W |
| ATM250T-□150 | 15.0V | 16.66A | 250W |
| ATM250T-□190 | 19.0V | 13.15A | 250W |
| ATM250T-□240 | 24.0V | 10.40A | 250W |
| ATM250T-□480 | 48.0V | 5.21A | 250W |
Specifications
| Input | |
| Voltage | 100-240VAC(Nominal), 90-264VAC(Range) |
| Frequency | 50-60Hz(Nominal), 47-63(Range) |
| Current | 3.3A-1.3A |
| Protection | Internal primary current fuse |
| Connector Configuration | IEC60320 / C14, C18 |
| Output | |
| Load Regulation | ±5% (Typical) |
| Ripple and Noise | ≤1% Vp-p @ Full Load |
| Transient (Dynamic) Response | 0.5mS at 50% load variation |
| Start-Up Time | < 3,000mS |
| Hold-Up Time | > 10mS @ Full Load |
| Rise Time | < 50mS |
| Protection | Short-Circuit Protection / Overvoltage Protection / Overcurrent Protection / Overtemperature Protection |
| Safety Certifications | |
| CB / UL / cUL / FCC / CE / TUV / PSE | |
| Electrical | |
| Topology | LLC |
| Withstand Voltage | 4,000VAC Primary - Secondary |
| Touch Current (Patient) | < 100µA |
| Earth Leakage Current | < 5mA |
| Efficiency | Complies with DoE Level VI, ErP Stage 2 |
| EMC Standards | EN55011 |
| EN61000-3-2,3 | |
| EN61000-4-2,3,4,5,6,8,11 | |
| MTBF (Mean Time Between Failures) | 300,000 hours calculated according to Telcordia SR-332 at 25°C |
| Environment | |
| Operating Temperature | -20 to +40°C |
| Storage Temperature | -20 to +80°C (In packaged condition) |
| Operating Altitude | 5,000M |
| Relative Humidity | Operating: 20 to 80% RH (Non-condensing) |
| Storage: 10 to 90% RH (In packaged condition) | |
| Cooling | Natural convection cooling |
| Mechanical | |
| Case Dimensions | Length 204 x Width 94 x Height 43.5 (mm) |
| Weight | 1,145g (Reference) |
